IMH10AT110 Rohm Semiconductor IMH10AT110 real image IMH10AT110 label picture IMH10AT110 label picture 2
Same model may have multiple batches, images only for reference.
IMH10AT110 Rohm Semiconductor IMH10AT110 real image IMH10AT110 label picture IMH10AT110 label picture 2
IMH10AT110 Rohm Semiconductor IMH10AT110 real image IMH10AT110 label picture IMH10AT110 label picture 2
Same model may have multiple batches, images only for reference.

IMH10AT110

Part No IMH10AT110
Manufacturer Rohm Semiconductor
Catalog Transistors (BJT) - Arrays, Pre - Biased
Description TRANS PREBIAS DUAL NPN SMT6
Datasheet
IMH10AT110 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Rohm Semiconductor
Packaging Reel - TR
Status Not For New Designs
Transistor Polarity 2 NPN - Pre-Biased (Dual)
Maximum Current Collector 100mA
VCEO Maximum Collector-Emitter Breakdown Voltage 50V
Resistor - Base (R1) (Ohms) 2.2k
Resistor - Emitter Base (R2) (Ohms) 47k
Typical Gain (hFE) (Min) 80 @ 10mA, 5V
Max Vce (sat) 300mV @ 250μA, 5mA
Collector Cut-off Current(Max) 500nA
Frequency - Transition 250MHz
Maximum Power Dissipation 300mW
Mounting SMD (SMT)
Case / Package SMT6
Win Source Part Number 017244-IMH10AT110
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IMH10AT110 CAD Model

Description

The Rohm Semiconductor IMH10AT110 is a dual NPN pre-biased transistor with a collector-emitter breakdown voltage of 50V.

  • Collector-Emitter Breakdown Voltage: 50V
  • Maximum Current Collector: 100mA
  • Maximum Power Dissipation: 300mW
  • Typical Gain: 80 @ 10mA and 5V
  • Frequency Transition: 250MHz
  • Collector Cut-off Current: 500nA
  • Maximum Vce (sat): 300mV @ 250μA and 5mA
  • Resistor-Base: 2.2k
  • Resistor-Emitter Base: 47k
