The RQ3E120ATTB is a 1200V, 3A silicon carbide (SiC) Schottky barrier diode (SBD) from Rohm Semiconductor. It is designed to offer superior performance compared to traditional silicon diodes, particularly in high-voltage and high-frequency applications. This device boasts a low forward voltage drop and minimal reverse recovery charge, enabling efficient and fast switching operation.

Applications

• Power Factor Correction (PFC) circuits
• Uninterruptible Power Supplies (UPS)
• Solar inverters
• Electric vehicle (EV) chargers
• Motor drives

Features

• High voltage capability: 1200V breakdown voltage allows use in high voltage applications.
• Low forward voltage (VF): Reduces conduction losses and improves efficiency.
• Zero reverse recovery current: Eliminates switching losses and reduces EMI.
• High surge current capability: Provides robustness against transient voltage spikes.
• High-speed switching: Enables high-frequency operation and reduces switching losses.
• Operating Temperature Range: -55°C to +175°C
• Package: TO-220AB

Benefits

• Improved energy efficiency: Lower switching and conduction losses translate to higher overall system efficiency.
• Reduced system size and cost: Higher switching frequencies allow for smaller passive components.
• Increased system reliability: Robust design and high surge current capability enhance system reliability.
• Simplified thermal management: Lower losses reduce heat generation, simplifying thermal design.
• Enhanced performance in high-frequency applications: Fast switching speed enables better performance in high-frequency power converters.

Additional Details

The RQ3E120ATTB is particularly well-suited for applications where high efficiency, high reliability, and compact size are critical. Its SiC technology enables significant improvements in performance compared to traditional silicon diodes. The device's low forward voltage and zero reverse recovery current contribute to reduced power losses and improved thermal management. The TO-220AB package facilitates easy mounting and heatsinking.

This SiC SBD offers a compelling solution for a wide range of power electronics applications, enabling designers to achieve higher efficiency, smaller size, and improved reliability in their systems.
