RSX301L-30TE25 Rohm Semiconductor RSX301L-30TE25 real image
Same model may have multiple batches, images only for reference.
RSX301L-30TE25 Rohm Semiconductor RSX301L-30TE25 real image
RSX301L-30TE25 Rohm Semiconductor RSX301L-30TE25 real image
Same model may have multiple batches, images only for reference.

RSX301L-30TE25

Part No RSX301L-30TE25
Manufacturer Rohm Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 30V 3A PMDS
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Rohm Semiconductor
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 420mV @ 3A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 200μA @ 30V
Mounting SMD (SMT)
Case / Package PMDS
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 027542-RSX301L-30TE25
Popularity Medium
Supply and Demand Status Balance
Quantity per package 1,500
Ultra Librarian 3D Model Ultra Librarian RSX301L-30TE25 CAD Model

Description

The RSX301L-30TE25 is a Schottky diode from Rohm Semiconductor.

  • Maximum Reverse Voltage: 30V
  • Average Rectified Current: 3A
  • Forward Voltage: 420mV @ 3A
  • Reverse Leakage Current: 200μA @ 30V
  • Mounting Type: SMD (SMT)
  • Package: reel-tr
  • Operating Temperature Range: Up to 150°C
