Same model may have multiple batches, images only for reference.

UM6K1NTN

Name: UM6K1NTN
Brand: Rohm Semiconductor
SKU: 387705
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	UM6K1NTN
Manufacturer	Rohm Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET 2N-CH 30V .1A SOT-363
Datasheet	UM6K1NTN Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Rohm Semiconductor
Packaging	Reel - TR
Status	Not For New Designs
FET Type	2 N-Channel (Dual)
FET Feature	Logic Level Gate
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	100mA
Maximum Rds On at Id,Vgs	8 Ohm @ 10mA, 4V
Gate-Source Threshold Voltage	1.5V @ 100μA
Max Input Capacitance	13pF @ 5V
Maximum Power Dissipation	150mW
Temperature Range - Operating	150°C (TJ)
Mounting	SMD (SMT)
Case / Package	UMT6
Win Source Part Number	035973-UM6K1NTN
Family Name	UM6K1N
Introduction Date	September 11, 1998
ECCN	EAR99
Halogen Free	Compliant
Estimated EOL Date	2019
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Ultra Librarian 3D Model	Ultra Librarian UM6K1NTN CAD Model

Alternative Products

Description

The UM6K1NTN is a Dual N-Channel Logic Level Gate FET from Rohm Semiconductor.

Drain-Source Breakdown Voltage: 30V
Continuous Drain Current @ 25°C: 100mA
Gate-Source Threshold Voltage: 1.5V @ 100μA
Rds On @ Id,Vgs: 8 Ohm @ 10mA, 4V
Power Dissipation: 150mW (Maximum)
Input Capacitance: 13pF @ 5V (Maximum)
Case/Package: UMT6
Suitable for: Discrete semiconductor products
