The SFMC-134-T2-F-D-K is a fine-pitch micro header connector manufactured by Samtec Inc., designed for high-density board-to-board connections. It is part of the SFMC series, known for its compact size, robust performance, and suitability for automated assembly processes.

Applications

• Board-to-Board Connections: Provides a reliable and space-efficient connection between PCBs.
• High-Density Interconnects: Used in applications where a large number of connections are required in a small area.
• Medical Devices: Suitable for medical equipment requiring compact and reliable interconnects.
• Industrial Automation: Employed in industrial control systems and automation equipment.
• Telecommunications Equipment: Used in telecommunications devices requiring high-speed data transmission.

Features

• Fine Pitch: Enables high-density connections with a small footprint.
• Surface Mount Technology (SMT): Designed for automated assembly processes.
• Dual Row Configuration: Maximizes the number of contacts in a limited space.
• 34 Positions per Row: Provides a total of 68 contacts.
• Samtec Tiger Eye™ Contacts: Ensures reliable and durable connections.
• Keyed: The 'K' at the end indicates a Keyed connector, preventing mismating.

Benefits

• Space Optimization: Fine pitch design allows for more components to be placed on the board.
• Reliable Connection: Tiger Eye™ contacts ensure a secure and long-lasting connection.
• Automated Assembly: SMT design simplifies the manufacturing process.
• High Contact Density: Dual row configuration maximizes the number of connections in a small area.
• Prevents Mismating: Keying feature ensures correct mating.
• Durable Construction: Withstands harsh environments and frequent mating cycles.

Additional Details

The SFMC-134-T2-F-D-K connector is constructed with high-quality materials to ensure optimal performance and longevity. The 'T2' likely refers to a specific plating option or material specification, enhancing corrosion resistance and signal integrity. The 'F' likely refers to a specific body material or feature. It is often used with Samtec's cable assemblies for a complete interconnect solution. The keyed feature adds an extra layer of protection against incorrect connections, which is crucial in complex electronic systems. Mates with FFSD, FFTP, and other compatible series from Samtec.
