SSM-120-S-DV-BE-K-TR

Name: SSM-120-S-DV-BE-K-TR
Brand: Samtec Inc.
SKU: 807592
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SSM-120-S-DV-BE-K-TR
Manufacturer	Samtec Inc.
Catalog	Rectangular Connectors
Description	CONN RCPT 40POS 0.1 GOLD SMD
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Samtec Inc.
Packaging	Reel
Connector Type	Receptacle, Bottom Entry
Contact Type	Female Socket
Style	Board to Board or Cable
Number of Positions	40
Number of Positions Loaded	All
Pitch - Mating	0.100" (2.54mm)
Number of Rows	2
Row Spacing - Mating	0.100" (2.54mm)
Mounting Style	SMD
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	30.0μin (0.76μm)
Insulation Color	Black
Insulation Height	0.290" (7.37mm)
Temperature Range - Operating	-55°C ~ 125°C
Contact Finish - Post	Tin
Features	Pick and Place
Current Rating (Amps)	5.2A per Contact
Voltage Rating	405VAC, 572VDC
Insulation Material	Liquid Crystal Polymer (LCP)
Contact Shape	Square
Contact Material	Phosphor Bronze
Manufacturer Pack Quantity	125
Popularity	Medium
Supply and Demand Status	Balance
Win Source Part Number	807592-SSM-120-S-DV-BE-K-TR
Ultra Librarian 3D Model	Ultra Librarian SSM-120-S-DV-BE-K-TR CAD Model

Alternative Products

Description

The Samtec Inc. 807592-SSM-120-S-DV-BE-K-TR is a receptacle bottom entry connector manufactured by Samtec Inc..

Positions: 40
Contact Type: Female Socket
Positions Loaded: All
Rows: 2
Mounting: Surface Mount
Termination: Solder
Fastening Type: Push-Pull
Contact Material: Phosphor Bronze
Contact Finish-Mating: Gold
Current: 5.2A per contact
Temperature Range: -55°C to 125°C
