RN202-1-02 Real Image
Same model may have multiple batches, images only for reference.

RN202-1-02

Part No RN202-1-02
Manufacturer Schaffner EMC Inc.
Catalog Common Mode Chokes
Description CMC 3MH 1A 2LN TH / 3 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 1A (Typ) DCR 205mOhm (Typ)
Datasheet
RN202-1-02 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters>Common Mode Chokes
Manufacturer Schaffner EMC Inc.
Packaging Tray
Product Status Obsolete
Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 3 mH @ 10 kHz
Current Rating (Max) 1A (Typ)
DC Resistance (DCR) (Max) 205mOhm (Typ)
Voltage Rating - AC 250V
Temperature Range - Operating -40°C ~ 125°C
Approval Agency UR, VDE
Mounting Through Hole
Size / Dimension 0.717" L x 0.346" W (18.20mm x 8.80mm)
Height (Max) 0.543" (13.80mm)
Case / Package Vertical, 4 PC Pin
RoHS Status RoHS Compliant
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Other Part Number 290-176,817-1559,-RN 202 1 /02,800450,RN202102
Standard Package 50
Win Source Part Number 1328219-RN202-1-02
Ultra Librarian 3D Model Ultra Librarian RN202-1-02 CAD Model

Description

The Schaffner EMC Inc. RN202-1-02 is a common mode choke filter designed to reduce electromagnetic interference in power line applications.

  • Voltage Rating: 250V AC
  • Current Rating: 1A (typ)
  • Inductance: 3mH @ 10kHz
  • Package: Vertical, 4 PC pin
  • Mounting: Through hole
  • Size: 0.717" L x 0.346" W (18.20mm x 8.80mm)
  • Height: 0.543" (13.80mm)
  • Compliance: RoHS compliant
  • Approvals: UR and VDE
