PQ070VK02FZH Real Image
Same model may have multiple batches, images only for reference.

PQ070VK02FZH

Part No PQ070VK02FZH
Manufacturer Sharp Microelectronics
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO ADJ 2A TO220-5
Datasheet
PQ070VK02FZH Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Sharp Microelectronics
Packaging Tube/Rail
Status Obsolete(EOL)
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 10V
Nominal Output Voltage (Min/Fixed) 1.5V
Maximum Output Voltage 7V
Dropout Voltage-Max 0.5V @ 2A
Output Current 2A
Operating Supply Current 2mA
PSRR 60dB (120Hz)
Control Features Enable
Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C to 85°C
Regulator Topology Positive Adjustable
Output Voltage 1.5 V to 7 V
Mounting Through Hole
Case / Package TO-220-5
Win Source Part Number 061995-PQ070VK02FZH
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PQ070VK02FZH CAD Model

Description

The Sharp Microelectronics 061995-PQ070VK02FZH is a positive adjustable regulator with a maximum input voltage of 10V and a nominal output voltage of 1.5V.

  • Dropout Voltage: 0.5V @ 2A
  • PSRR: 60dB (120Hz)
  • Protection Features: over current and over temperature
  • Mounting Type: surface mountable
  • Application: integrated circuits applications
  • Supply and Demand Status: limited
  • Operating Temperature: -40°C to 85°C
