The SI4532ADY-T1 is a P-Channel MOSFET manufactured by Silicon Labs (formerly Siliconix). It is designed for load switching and power management applications. This MOSFET features a low on-state resistance (RDS(on)) and is available in a compact SO-8 package.

Applications

• Load Switching
• Power Management
• DC-DC Conversion
• Battery Protection
• Power Distribution

Features

• Voltage Rating: 30V
• On-State Resistance (RDS(on)): 28 mΩ (typical) at VGS = -10V
• Gate Charge (Qg): 14 nC (typical)
• Continuous Drain Current (ID): -7.7A
• Pulsed Drain Current (IDM): -30A
• Operating Junction Temperature: -55°C to +150°C
• Package: SO-8
• Lead-Free, Halogen-Free

Benefits

• Low RDS(on) minimizes power losses and improves efficiency.
• Compact SO-8 package saves board space.
• Lead-free and Halogen-Free, meeting environmental regulations.
• Designed for load switching and power management circuits

Additional Details

The SI4532ADY-T1 is a reliable P-Channel MOSFET for general purpose switching. The SO-8 package is industry standard and easy to use in existing designs. The datasheet shows further details on safe operating area, thermal resistance, and gate threshold voltage characteristics. The low on-resistance is one of the device's selling points.
