Same model may have multiple batches, images only for reference.
SKY13698-694EK1 Real Image
Same model may have multiple batches, images only for reference.

SKY13698-694EK1

Part No SKY13698-694EK1
Manufacturer Skyworks Solutions Inc.
Catalog RF Evaluation and Development Kits, Boards
Description EVALUATION BOARD/KIT / SKY13698-694LF series Switch, DPDT Evaluation Board
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Development Boards, Kits, Programmers>RF Evaluation and Development Kits, Boards
Mfr Skyworks Solutions Inc.
Package Box
Type Switch, DPDT
Frequency 400MHz ~ 5.9GHz
For Use With/Related Products SKY13698-694LF
Supplied Contents Board(s)
Base Product Number SKY13698
MSL Level 1 (Unlimited)
ECCN 3B992
HTSUS 8543.70.9860
Other Names 863-2059
Standard Package 1
Win Source Part Number 1130419-SKY13698-694EK1
Ultra Librarian 3D Model Ultra Librarian SKY13698-694EK1 CAD Model

Description

The SKY13698-694EK1 is a switch DPDT development board designed for use with SKY13698-694LF. It has a Win Source Part Number of 1130419-SKY13698-694EK1 and is categorized under development boards, kits, programmers>RF evaluation and development kits, boards. The board is supplied with a frequency range of 400MHz to 5.9GHz and has a standard package of 1. The ECCN for this product is 3B992 and the HTSUS code is 8543.70.9860.
