ECMF4-2450A60N10 by STMicroelectronics

The ECMF4-2450A60N10 is a state-of-the-art integrated common mode filter designed by STMicroelectronics, tailored for high-speed differential data lines protection. This robust component is engineered to provide superior common mode noise suppression, ensuring signal integrity for applications that demand high-speed data transmission and exceptional performance.

Key Features

• High Differential Bandwidth: With a differential bandwidth of up to 6 GHz, the ECMF4-2450A60N10 is well-suited for high-speed interfaces such as USB 3.1 Gen 1, HDMI, and DisplayPort, providing minimal impact on signal quality.
• Enhanced ESD Protection: This device offers an impressive level of Electrostatic Discharge (ESD) protection, meeting IEC 61000-4-2 level 4 standards. This ensures that sensitive electronic equipment is safeguarded against the harmful effects of ESD events.
• Low Insertion Loss: The ECMF4-2450A60N10 is designed to maintain a low insertion loss, which is crucial for preserving the integrity of high-speed signals over the transmission path.
• Very Large Differential Impedance Range: This component supports a wide range of differential impedances, making it highly adaptable to various high-speed differential signal requirements.
• Compact Package: Housed in a space-saving flip-chip package, the ECMF4-2450A60N10 minimizes PCB real estate usage without compromising on performance, making it ideal for compact electronic devices.

Applications

The ECMF4-2450A60N10 is a versatile solution that can be integrated into a multitude of applications, including:

• Smartphones, Tablets, and Laptops
• High-Resolution Video Interfaces
• USB Hubs, Peripherals, and Docking Stations
• High-Speed Data Line Protection for Consumer Electronics

STMicroelectronics' commitment to quality and performance is evident in the ECMF4-2450A60N10, making it a top choice for designers and engineers who require a reliable common mode filter for their high-speed data line applications. With its superior noise suppression capabilities, robust ESD protection, and compatibility with high-speed signal standards, this product stands out as a leading solution in the field of signal integrity and protection.
