Products specifications

Category Development Boards, Kits, Programmers - Evaluation and Demonstration Boards and Kits
Mfr STMicroelectronics
Package Bulk
Type Power Management
Function Motor Controller/Driver
Utilized IC / Part VNH7070BAS
Supplied Contents Board(s)
Base Product Number EV-VNH7070
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1341614-EV-VNH7070BAS
Ultra Librarian 3D Model Ultra Librarian EV-VNH7070BAS CAD Model

Description

STMicroelectronics EV-VNH7070BAS Automotive-Grade H-Bridge Driver

The EV-VNH7070BAS from STMicroelectronics is a highly integrated solution designed for automotive and industrial applications requiring high current control with diagnostic functions. This product is a part of the VNH7S series, which is renowned for its robustness and efficiency in controlling motor and actuator loads.

At the heart of the EV-VNH7070BAS is an H-bridge driver capable of delivering up to 70A of continuous current, making it suitable for high-power applications such as automotive brush DC motor driving. The device operates within a voltage range of 5.5 V to 16 V, which is ideal for 12V automotive systems, and it is protected against reverse polarity, enhancing its reliability in challenging environments.

One of the key features of the EV-VNH7070BAS is its built-in diagnostic capabilities. The product provides real-time feedback on various parameters such as load current, electrical and thermal overload, and short circuit detection. This allows for immediate troubleshooting and enhances the safety and longevity of the control system.

The EV-VNH7070BAS is also designed with ease of use in mind. It includes an SPI interface for digital control, which simplifies the integration with microcontroller units (MCUs) and allows for fine-grained control over the motor functions. Additionally, the product comes in a compact PowerSSO-36 package, which is suitable for space-constrained applications.

With its robust design and comprehensive protection features, the EV-VNH7070BAS is not only suited for automotive applications such as window lifters, seat adjusters, and HVAC blowers, but also for a wide range of industrial applications where reliable motor control is critical.

Overall, the EV-VNH7070BAS is a testament to STMicroelectronics' commitment to delivering high-quality and durable products that meet the stringent requirements of the automotive industry and beyond.
