Product Overview: L297 Stepper Motor Controller

The L297 from STMicroelectronics is a comprehensive stepper motor controller designed to drive both windings of a bipolar stepper motor or bidirectionally control two DC motors. It is a versatile chip that offers a wide range of features to accommodate the varied demands of complex motor control applications.

Key Features

• Dual Full-Bridge Driver: The L297 can be paired with a dual full-bridge driver such as the L298N to form a complete driver for bipolar stepper motors.
• Programmable Control: It includes control logic and a programmable divider, which allows for complete control over the stepper motor's phase sequence, thus enabling precise motor movement.
• Multiple Operation Modes: The device supports various modes of operation including full step, half step, and microstep modes, providing flexibility to match the application's resolution requirements.
• Chopper Drive Capability: The chopper drive feature ensures efficient current regulation, which is essential for controlling the motor's torque and reducing power dissipation.
• Integrated Protection Features: It comes with built-in thermal shutdown and overcurrent protection, which helps to prevent damage to the controller under fault conditions.

Applications

The L297 stepper motor controller is ideal for a wide range of applications that require precise motor control. It is commonly used in:

• CNC machines
• 3D printers
• Robotics
• Automated equipment
• Office automation machines

Technical Specifications

• Supply Voltage: The device operates at a supply voltage range of 4.75V to 7V for the logic circuits and up to 46V for the motor power supply.
• Output Current: It can handle output currents up to 2A per channel.
• Package: The L297 is available in a 20-pin DIP (Dual In-line Package) or a 20-pin PLCC (Plastic Leaded Chip Carrier) format.

Overall, the L297 stepper motor controller from STMicroelectronics represents a robust solution for complex motor driving applications that require reliability, precision, and versatility.
