Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Applications DC Motors, Stepper Motors, Voltage Regulators
Load Type Inductive
Technology DMOS
Rds On (Typ) 300 mOhm
Channel Output Current 2.8A
Current - Peak Output 5.6A
Supply Voltage - Operating 8 V to 52 V
Voltage - Load 8 V to 52 V
Temperature Range - Operating -25°C to 125°C (TJ)
Features Bootstrap Circuit
Fault Protection Current Limiting, Over Temperature, UVLO
Mounting SMD (SMT)
Case / Package PowerSO-36
Win Source Part Number 018261-L6207PD013TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian L6207PD013TR CAD Model

Description

STMicroelectronics L6207PD013TR Motor Driver

The L6207PD013TR from STMicroelectronics is a high-performance dual full-bridge driver that is designed to drive bipolar stepper motors or bidirectional control of two DC motors. This integrated circuit is housed in a PowerSO-36 package and is part of the L6207 series known for its efficiency and reliability in motor control applications.

With an operating voltage range from 8V to 52V, the L6207PD013TR is versatile enough to cater to a wide array of applications. It boasts an impressive output current capability of up to 2.8A, making it suitable for driving a large range of motor sizes. Furthermore, the device integrates all the circuitry needed to drive motors with simple directional and speed control inputs.

The driver features cross-conduction protection, thermal shutdown, and non-dissipative overcurrent protection, ensuring the safety and longevity of both the driver and the motors it controls. Its internal synchronous rectification control circuitry significantly improves power efficiency, especially at low speeds, which is a critical feature for battery-powered applications.

One of the key advantages of the L6207PD013TR is its ease of use. It requires minimal external components, reducing the complexity of the design and the overall bill of materials. The device also supports microstepping operation, enabling precise control of stepper motors, which is essential for applications that require fine positioning and smooth motion profiles.

Applications for the L6207PD013TR are diverse and include industrial automation, robotics, office automation equipment, and consumer electronics. Whether it's controlling the precise movement in a 3D printer or managing the motors in an automated conveyor system, this motor driver is an excellent choice for designers looking for a reliable and efficient solution.

The L6207PD013TR is available in tape and reel packaging, making it suitable for high-volume production and automated assembly processes. With its robust feature set and STMicroelectronics' reputation for quality, this motor driver is a solid choice for any motor control solution.
