Products specifications

Category Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Regulators - DC DC Switching Regulators
Mfr STMicroelectronics
Series -
Package Tape & Reel
Product Status Active
Function Step-Down
Output Configuration Positive
Topology Buck
Output Type Fixed
Number of Outputs 1
Voltage - Input (Min) 3.5V
Voltage - Input (Max) 38V
Voltage - Output (Min/Fixed) 5V
Voltage - Output (Max) -
Current - Output 1.5A
Frequency - Switching 400kHz
Synchronous Rectifier Yes
Temperature Range - Operating -40°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package 8-SO
Base Product Number L6981
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1372223-L6981C50DR
Ultra Librarian 3D Model Ultra Librarian L6981C50DR CAD Model

Description

Introducing the L6981C50DR from STMicroelectronics

The L6981C50DR is a state-of-the-art synchronous step-down switching regulator, meticulously engineered by STMicroelectronics, a leader in semiconductor solutions. This highly efficient power management component is designed to meet the rigorous demands of modern electronic applications, including but not limited to consumer electronics, networking devices, and industrial systems.

Key Features

  • High Efficiency: The L6981C50DR boasts an impressive efficiency level, which not only reduces power loss but also minimizes the heat generated during operation.
  • Wide Input Voltage Range: This regulator can operate over a broad input voltage range from 4 V to 38 V, accommodating a variety of power sources and fluctuating voltages.
  • Adjustable Output Voltage: Users can set the output voltage from 0.85 V to VIN, ensuring versatility and compatibility with a wide array of devices and applications.
  • Compact Footprint: The device comes in an HTSSOP16 package, which is ideal for space-constrained applications without compromising on performance.
  • Protection Features: It includes overcurrent protection, thermal shutdown, and overvoltage protection, enhancing the reliability and longevity of both the regulator and the end application.

Applications

The L6981C50DR is an excellent choice for a myriad of applications. Its robust design is particularly well-suited for:

  • Consumer electronics such as set-top boxes, gaming consoles, and LED TVs
  • Telecommunication equipment like routers and switches
  • Industrial systems, including factory automation and control units
  • Point-of-Load (POL) conversions in complex multi-rail systems

Technical Specifications

With a switching frequency range of 200 kHz to 2.2 MHz, which is adjustable via an external resistor or synchronized to an external clock, the L6981C50DR provides design flexibility. It supports a maximum output current of 800 mA, making it suitable for a wide range of low-to-medium power applications.

In summary, the L6981C50DR from STMicroelectronics is a versatile and reliable solution for your power supply needs, offering efficiency, flexibility, and safety with its advanced features and protections.
