Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 44 Weeks
Features Switching Regulator IC Output
Manufacturer STMicroelectronics
Package Reel - TR
Family Name L7980
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number 479-10721-2, 479-10721-2-ND, 479-10721-1, 479-10721-1-ND, 497-10721-6, -497-10721-1, 479-10721-6-ND, 479-10721-6, -497-10721-2, 497-10721-2, 497-10721-1
Quantity per package 2500
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 846602-L7980ATR
Ultra Librarian 3D Model Ultra Librarian L7980ATR CAD Model

Description

Introducing the L7980ATR Switching Regulator from STMicroelectronics

The L7980ATR from STMicroelectronics is a state-of-the-art step-down switching regulator that boasts an impressive efficiency and flexibility, designed to meet the demanding needs of modern electronic applications. This high-performance component is ideal for a variety of applications, ranging from consumer electronics to industrial systems, where power efficiency and compact size are critical.

The L7980ATR operates over a wide input voltage range from 4.5 V to 28 V, making it suitable for use with a variety of input sources. This versatility ensures that it can adapt to diverse operating conditions and is compatible with many different types of electronic equipment.

One of the key features of the L7980ATR is its high efficiency, which is achieved through an advanced switching technology that minimizes power loss during operation. This not only helps in reducing heat generation but also extends the life of the product by preventing thermal stress on the components. With a maximum output current of 2 A, this regulator can easily handle a wide range of power requirements.

The L7980ATR also offers a high level of integration, incorporating internal compensation and a fixed frequency oscillator that simplifies the design and reduces external component count. This integration contributes to a more compact and reliable design, which is essential for applications with limited space.

Additionally, the device provides several protection features to ensure the safety and reliability of the end application. These include over-current protection, thermal shutdown, and a power-good flag that offers an early warning for voltage regulation errors, thus safeguarding the system from potential damage.

With its adjustable output voltage, which can be set from 1 V to VIN with external resistors, designers have the flexibility to tailor the L7980ATR to the specific needs of their applications. The switching frequency is also adjustable from 200 kHz to 2 MHz, allowing for optimization between efficiency and component size.

In summary, the L7980ATR from STMicroelectronics is a robust and efficient solution for any design requiring a compact, high-performance step-down regulator. Its wide input voltage range, high efficiency, and advanced protection features make it an excellent choice for a broad array of power management applications.
