Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Memory Format EEPROM
Technology EEPROM
Memory Size 2Mb (256K x 8)
Max Frequency 5MHz
Supply Voltage - Operating 1.8 V to 5.5 V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 141087-M95M02-DRMN6TP
Family Name M95M02-DR
Introduction Date February 01, 1991
ECCN 3A991.b.1.b.1
Country of Origin United States of America
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian M95M02-DRMN6TP CAD Model

Description

The M95M02-DRMN6TP is a 2 Mbit serial EEPROM memory module from STMicroelectronics, designed to provide robust, high-capacity storage solutions for advanced electronic applications. This EEPROM (Electrically Erasable Programmable Read-Only Memory) device utilizes the standard SPI (Serial Peripheral Interface) protocol, ensuring easy integration into a wide array of microcontroller-based systems.

Key Features

  • High Density: With a storage capacity of 2 Mbit, this EEPROM provides ample space for firmware storage, configuration settings, or any data that requires long-term retention without power.
  • Serial Interface: The M95M02-DRMN6TP communicates via a fast SPI bus, capable of clock frequencies up to 10 MHz, facilitating quick data transfers.
  • Wide Voltage Range: It operates across a wide voltage range of 1.8V to 5.5V, making it versatile for use in various electronic environments and compatible with many microcontrollers and digital systems.
  • Enhanced Data Protection: The device includes write protect features and a hardware protection mechanism to prevent inadvertent writes, thereby ensuring the integrity of the stored data.
  • Extended Temperature Range: Its robust design allows for operation in extended temperature ranges, from -40°C to +85°C, suitable for industrial applications.

Applications

The M95M02-DRMN6TP is ideal for a variety of applications that require reliable non-volatile memory storage. These include:

  • Advanced industrial automation and control systems
  • Consumer electronics configuration storage
  • Medical devices that require data logging capabilities
  • Automotive systems where long-term data retention is crucial
  • Telecommunication infrastructure and networking equipment

Package and Quality

This EEPROM is available in an 8-pin SO N (Narrow) package, denoted by the "M" at the end of its product code, ensuring compatibility with standard surface-mount technology (SMT) manufacturing processes. STMicroelectronics is committed to the highest quality standards, and the M95M02-DRMN6TP is no exception, meeting stringent industry requirements for performance and reliability.

For detailed specifications, datasheets, and more information about the M95M02-DRMN6TP EEPROM, visit the STMicroelectronics website or contact their support team.
