Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tube
Status Obsolete
Function Step-Up, Step-Down
Output Configuration Positive or Negative
Topology Buck, Boost
Output Type Adjustable
Voltage - Input (Minimum) 3V
Voltage - Input (Maximum) 40V
Min/Fixed Output Voltage 1.25V
Maximum Output Voltage 38V
Output Current 1.5A (Switch)
Switching Frequency 100kHz
Temperature Range - Operating 0°C ~ 70°C
Mounting Style SMD
Manufacturer Package 8-SOIC
Supplier Device Package 8-SO
Family Part Number MC34063E
Manufacturer Pack Quantity 2,000
MSL Level 1 (Unlimited)
Win Source Part Number 1218584-MC34063ECD
Manufacturer Homepage www.st.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MC34063ECD CAD Model

Description

STMicroelectronics MC34063ECD Step-Up/Down/Inverting Switching Regulator

The MC34063ECD from STMicroelectronics is a versatile monolithic DC-DC converter integrated circuit that is capable of performing step-up, step-down, and voltage-inverting applications with a minimum number of external components. This highly reliable IC is designed to facilitate easy and efficient design of power conversion solutions for a wide range of products.

Key Features:

  • Adjustable Output Voltage: The output voltage can be set to the desired level using external resistors.
  • Wide Input Voltage Range: It operates from an input voltage range of 3V to 40V, making it suitable for battery-operated devices as well as automotive applications.
  • High Precision: Voltage precision can be achieved due to its tight reference voltage tolerance.
  • Low Standby Current: The quiescent current is low, which enhances the power efficiency, especially in battery-powered devices.
  • Switching Frequency: The oscillator frequency can be adjusted through an external resistor and capacitor, providing design flexibility.
  • Output Switch Current: Its output can handle up to 1.5A, making it capable of driving a wide range of loads.
  • Thermal Shutdown: It includes a thermal shutdown feature that protects the device from overheating.
  • Short Circuit Protection: The built-in short circuit protection ensures safety and reliability under abnormal conditions.

Applications:

The MC34063ECD is ideal for creating efficient power solutions in a variety of applications, including:

  • DC-DC converters for personal computers and peripherals
  • Automotive applications such as power adapters
  • Battery chargers
  • Portable instruments
  • LED drivers

Package and Quality:

STMicroelectronics offers the MC34063ECD in a compact SOP-8 package, which is suitable for space-constrained applications. The device is manufactured to high standards, ensuring both performance reliability and adherence to environmental regulations.
