The STB11NM80 is a state-of-the-art N-channel Power MOSFET presented by STMicroelectronics, designed with the advanced MDmesh™ technology. This power MOSFET is a highly efficient device that offers a perfect blend of low on-resistance and high blocking voltage, making it an ideal choice for a wide range of high voltage applications that require superior power density and efficiency.
With a robust and rugged design, the STB11NM80 boasts an impressive 800V blocking voltage, which provides a significant margin for high voltage applications, ensuring reliability and longevity. The device's low on-resistance of 0.85Ω minimizes conduction losses, contributing to its excellent efficiency. Additionally, the MOSFET's high current capability of 11A allows for exceptional performance in high-power circuits.
The STB11NM80 is available in multiple package options, including D2PAK, I2PAK, TO-220, and TO-220FP, offering designers the flexibility to choose the appropriate package based on thermal and space considerations. This versatility makes it suitable for a variety of applications, such as switch-mode power supplies (SMPS), lighting applications, high-efficiency converters, and power management solutions.
Engineered with the innovative MDmesh™ technology, this device provides a significant reduction in switching losses. This technology combines with the device's inherent features to ensure a high performance in resonant and hard-switching topologies, as well as in applications that require high switching frequencies.
Key features of the STB11NM80 include:
- High dv/dt and avalanche capabilities
- Low gate charge and input capacitance
- Fast recovery diode
- 100% avalanche tested
- Zener-protected
STMicroelectronics' commitment to innovation and quality ensures that the STB11NM80 MOSFET meets the stringent requirements of modern electronic systems, delivering performance, efficiency, and reliability that designers can trust.
