Products specifications

Categories Discrete Semiconductor Products
Estimated Pruduction Lead Time 37 Weeks
Features N-Channel 600 V 12A (Tc) 90W (Tc) Surface Mount D²PAK (TO-263)
Manufacturer STMicroelectronics
Series MDmesh™ DM2
Package Reel - TR
Operating Temperature Range 150°C (TJ)
Mounting Surface Mount
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Case / Package D2PAK (TO-263)
Family Name STB18
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Other Part Number 497-16339-6, 497-16339-1, 497-16339-2
Quantity per package 1000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 935233-STB18N60DM2
Ultra Librarian 3D Model Ultra Librarian STB18N60DM2 CAD Model

Description

The STB18N60DM2 is a state-of-the-art N-Channel MOSFET brought to you by STMicroelectronics, designed to deliver high efficiency and power density for a wide range of applications. This device is part of the MDmesh™ DM2 series, which utilizes an innovative proprietary vertical structure that combines a high voltage breakdown with low on-resistance, optimizing it for high-performance switching applications.

Key Features

  • Voltage Rating: The STB18N60DM2 boasts a robust maximum voltage rating of 600V, making it suitable for high voltage applications.
  • On-Resistance: It features a low on-resistance (R<sub>DS(on)) of typically 0.165 Ω, ensuring minimal power loss and improved efficiency.
  • Current Capability: This MOSFET has a continuous drain current (I<sub>D) of 18A at 25°C, providing ample current for a variety of uses.
  • Fast Switching Speed: With fast switching performance, the STB18N60DM2 enhances power efficiency and reduces switching losses.
  • Temperature Performance: It is designed to perform reliably over a wide operating temperature range, making it suitable for challenging environments.
  • 100% Avalanche Tested: Guaranteed reliability and robustness in applications subject to high energy pulses.
  • Low Gate Charge: Reduced gate charge (Q<sub>g) facilitates faster switching and lower driving power.

Applications

The STB18N60DM2 is ideal for a range of power applications, including:

  • Switch Mode Power Supplies (SMPS)
  • LED Lighting
  • High-Efficiency DC-DC Converters
  • Welding Equipment
  • Uninterruptible Power Supplies (UPS)
  • Motor Control

Package and Quality

This MOSFET comes in a TO-220 package, which is widely used and allows for easy mounting and heat dissipation. STMicroelectronics ensures the highest quality and reliability of its products, and the STB18N60DM2 is no exception, meeting rigorous industry standards for performance and durability.
