Products specifications

Reference Date Code 0840+
Reference case TO251
Manufacturer STMicroelectronics
Manufacturer Homepage www.st.com
Win Source Part Number 720584-STD1LNK60Z
Popularity Low
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STD1LNK60Z CAD Model

Description

The STD1LNK60Z is a cutting-edge power MOSFET designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This device is part of the STripFET™ II family of power MOSFETs that are known for their low on-state resistance and high switching performance. The STD1LNK60Z is particularly suited for a wide range of applications where power efficiency and reliability are of utmost importance.

Key Features

  • Low Threshold Drive: The device can be driven at low gate voltages, making it compatible with a wide range of drive circuits and allowing for reduced power consumption during operation.
  • High Switching Performance: With fast switching speeds, the STD1LNK60Z is capable of handling high-frequency applications, contributing to improved overall efficiency.
  • Low On-State Resistance (R<sub>DS(on)): The low resistance when the device is on ensures minimal voltage drop across the MOSFET and reduces power loss.
  • High Avalanche Ruggedness: The device is designed to withstand high energy pulses in the avalanche and commutation modes, providing reliable performance under harsh conditions.
  • 100% Avalanche Tested: Each unit is tested for guaranteed performance in applications requiring ruggedness.
  • Zener-Protected: The built-in Zener diodes provide protection against electrostatic discharge (ESD) and enhance the overall ruggedness of the device.

Applications

The STD1LNK60Z is versatile and can be used in a variety of applications including:

  • Switching regulators
  • DC/DC converters
  • Motor control circuits
  • Power management functions
  • LED lighting solutions
  • Automotive applications
  • High-efficiency power supplies

Package and Environmental Compliance

The STD1LNK60Z is available in a surface-mount DPAK package, which is designed for compact and high-power-density applications. It is also compliant with RoHS and Halogen-free standards, ensuring an environmentally friendly product that meets current global environmental regulations.

Conclusion

The STD1LNK60Z from STMicroelectronics represents a smart choice for designers looking for a power MOSFET that combines efficiency, reliability, and environmental consciousness. With its robust feature set and versatile application range, this device is well-suited to meet the demands of modern electronic designs.
