Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 24A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 5V, 10V
Gate-Source Threshold Voltage 1V @ 250μA
Max Gate Charge 28nC @ 5V
Max Input Capacitance 1670pF @ 25V
Maximum Gate-Source Voltage ±16V
Power Dissipation (Max) 70W (Tc)
Maximum Rds On at Id,Vgs 28 mOhm @ 12A, 10V
Temperature Range - Operating 175°C (TJ)
Mounting SMD (SMT)
Case / Package D-Pak
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 031133-STD30PF03LT4
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian STD30PF03LT4 CAD Model

Description

STD30PF03LT4 from STMicroelectronics is a MOSFET product used in switching and power-control designs where engineers need a reliable semiconductor solution from a widely recognized manufacturer. While the input category lists Transistors - FETs, MOSFETs - RF, designers should verify the exact device classification, package, and electrical characteristics against the official STMicroelectronics datasheet before committing it to a new design. This part may be evaluated for use in power management stages, load switching, DC motor control, converter sections, and other circuit blocks that depend on MOSFET behavior and stable sourcing history. From a positioning standpoint, it is most relevant for engineers balancing brand preference, documentation quality, and procurement practicality. Lifecycle status is currently information not available, so supply continuity should be reviewed before volume release. RoHS compliance information is also not available from the provided input; engineers and buyers should confirm current compliance and material declarations directly with the manufacturer or authorized channels.
