Products specifications

Categories Discrete Semiconductor Products
Estimated Pruduction Lead Time 37 Weeks
Features N-Channel 650 V 5A (Tc) 60W (Tc) Surface Mount D-PAK (TO-252)
Manufacturer STMicroelectronics
Series MDmesh™ M6
Package Reel - TR
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Surface Mount
Package TO-252-3, DPak (2 Leads + Tab), SC-63
Case / Package D-PAK (TO-252)
Family Name STD7N65
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Quantity per package 2500
Popularity High
Supply and Demand Status Balance
Win Source Part Number 897932-STD7N65M6
Ultra Librarian 3D Model Ultra Librarian STD7N65M6 CAD Model

Description

Product Overview: STD7N65M6 - STMicroelectronics

The STD7N65M6 is a state-of-the-art power MOSFET designed and manufactured by STMicroelectronics, a global semiconductor leader known for its innovative and reliable products. This particular MOSFET is part of the MDmesh™ M6 series, which features extremely low on-resistance, high dv/dt capability, and fast switching performance. It is specifically engineered to address the efficiency demands of a wide range of applications, including switch-mode power supplies (SMPS), lighting, DC-DC converters, and high-efficiency converters.

Key Features

  • Voltage Rating: The STD7N65M6 has a drain-source voltage (V<sub>DS) of 650V, making it suitable for high voltage applications.
  • Current Capacity: It supports a continuous drain current (I<sub>D) of 7A, which allows it to handle significant power levels.
  • RDS(on) Performance: With an on-resistance (RDS(on)) as low as 0.54Ω, it ensures high efficiency and minimal power loss during operation.
  • Fast Switching: The device exhibits fast switching performance, which is crucial for reducing switching losses and improving overall efficiency.
  • Robustness: It is designed to withstand high dv/dt rates, enhancing its reliability and longevity in demanding environments.
  • Package: The STD7N65M6 comes in a surface-mount PowerFLAT™ 5x6 package, which combines compact size with excellent thermal performance.

Applications

The versatility of the STD7N65M6 allows it to be used in a variety of applications. It is particularly well-suited for:

  • LED lighting drivers
  • Switch-mode power supplies (SMPS)
  • Power factor correction (PFC) circuits
  • Adapters and chargers
  • Solar inverters
  • Welding equipment

Conclusion

With its high voltage capability, low on-resistance, and fast switching performance, the STD7N65M6 from STMicroelectronics is an excellent choice for designers looking to optimize power efficiency and reliability in their electronic designs. Its robustness and versatility make it a valuable component for a broad spectrum of power applications.
