Products specifications

Category Development Boards, Kits, Programmers>Evaluation and Demonstration Boards and Kits
Mfr STMicroelectronics
Package Bulk
Product Status Obsolete
Type Power Management
Function Motor Controller/Driver
Embedded Yes, MCU, 16-Bit
Utilized IC / Part ST10F276
Primary Attributes Flash MCU with DSP Functionalities
Supplied Contents Board(s)
Secondary Attributes CAN, I²C, RS-232 and RS-485 Interfaces
Other Names 497-6399,STEVAL-IFN001V2
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN 3B992
HTSUS 8473.30.1180
Win Source Part Number 1284500-STEVAL-IFN001V2
Ultra Librarian 3D Model Ultra Librarian STEVAL-IFN001V2 CAD Model

Description

The STEVAL-IFN001V2 is a highly versatile evaluation board from STMicroelectronics, designed specifically for industrial applications. This board is centered around the robust L6360 IO-Link master transceiver and is an essential tool for developers and engineers looking to explore the capabilities of IO-Link communication protocols in their industrial systems.

Key Features

  • L6360 IO-Link Master Transceiver: The heart of the STEVAL-IFN001V2 is the L6360 transceiver, which facilitates bidirectional communication and provides a robust interface between the controller and sensors/actuators.
  • Multi-Protocol Support: The board supports IO-Link (COM1, COM2, COM3 modes), SIO mode, and I2C interface, making it highly adaptable to various communication requirements.
  • Integrated Protection Features: The STEVAL-IFN001V2 is designed with protection in mind, featuring over-temperature protection, CQ pin short-circuit protection, and under-voltage lockout to ensure reliable operation in industrial environments.
  • Easy-to-Use Interface: It comes with a user-friendly interface, including LED indicators for status and diagnostics, making it easier to monitor and debug the system.
  • Flexible Power Supply: The board is equipped with a wide range power supply input, catering to various industrial applications.
  • Configurable Settings: Onboard jumpers and trimmers allow for easy configuration and customization of settings to match specific application requirements.

Applications

The STEVAL-IFN001V2 is ideal for a range of industrial applications, including factory automation, process control, and machine tools. Its robust design and communication capabilities make it suitable for developing sophisticated industrial systems with advanced diagnostic and monitoring features.

Why Choose STEVAL-IFN001V2?

For developers looking to streamline their industrial communication systems, the STEVAL-IFN001V2 offers a compact, powerful, and highly adaptable solution. Its combination of the L6360 transceiver, multi-protocol support, and comprehensive protection features provide a reliable platform for developing and testing IO-Link master applications with confidence.
