Products specifications

Category Development Boards, Kits, Programmers>Evaluation Boards - LED Drivers
Mfr STMicroelectronics
Package Box
Product Status Obsolete
Current - Output / Channel 370mA
Outputs and Type 1, Non-Isolated
Voltage - Output 17V ~ 25V
Voltage - Input 96 ~ 132 VAC
Supplied Contents Board(s)
Utilized IC / Part L6562A
Other Names 497-11281,STEVALILL034V1
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1283869-STEVAL-ILL034V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-ILL034V1 CAD Model

Description

STEVAL-ILL034V1 - LED Driver Evaluation Board from STMicroelectronics

The STEVAL-ILL034V1 is a highly efficient evaluation board designed by STMicroelectronics, tailored for LED lighting applications. This innovative evaluation platform showcases the performance of the LED6000 step-down monolithic switching regulator, which is optimized to operate at high efficiency across a wide range of operating conditions. The LED6000 is particularly suitable for driving high-brightness LEDs with a constant current that can be easily adjusted via external components.

Featuring a wide input voltage range from 4.5V to 61V, the STEVAL-ILL034V1 is versatile and can be used in a variety of lighting scenarios, from low-voltage automotive applications to industrial lighting systems. The board is designed to deliver up to 3A of output current, ensuring that it can power a broad array of LED configurations.

The STEVAL-ILL034V1 integrates a number of protection features to ensure the longevity and reliability of the system. These include overcurrent protection, thermal shutdown, and LED short-circuit protection. Additionally, the board supports pulse-width modulation (PWM) dimming, which provides users with precise control over the brightness levels of their LED lighting solutions.

The compact design of the STEVAL-ILL034V1, along with its pre-configured setup, allows for quick and easy evaluation, making it an excellent tool for designers and engineers looking to test and implement LED driving solutions in their products. The evaluation board comes with a detailed user manual and schematic diagrams, aiding in the understanding of the LED6000 regulator's operation and facilitating the integration of the board into larger systems.

Overall, the STEVAL-ILL034V1 from STMicroelectronics is an exceptional resource for those seeking to develop energy-efficient, high-performance LED lighting applications. Its robust feature set, combined with the quality and support provided by STMicroelectronics, makes it an indispensable tool for rapid prototyping and testing in the field of LED lighting technology.
