The STEVAL-ILL074V1 from STMicroelectronics is a state-of-the-art LED driver evaluation board designed for testing and optimizing LED lighting solutions. This compact and versatile board is part of ST's evaluation platforms aimed at helping developers and engineers accelerate the design process for LED lighting applications.

Key Features

• Integrated STLED316S six-channel LED driver with error detection
• Support for wide input voltage range from 6V to 48V
• Up to 85% efficiency for optimal energy usage
• Dimming control via PWM (Pulse Width Modulation)
• Thermal shutdown and overcurrent protection for improved safety
• LED error detection capabilities for enhanced reliability
• Flexible LED configuration options for various lighting setups
• Easy-to-use graphical user interface (GUI) for quick setup and adjustments

Applications

The STEVAL-ILL074V1 is suitable for a wide range of LED lighting applications, including:

• Architectural lighting
• Interior car lighting
• General purpose LED lighting
• Signal and marker lights for industrial applications

Design & Development

Equipped with the STLED316S driver, the STEVAL-ILL074V1 supports a variety of LED driving methods, offering flexibility in design. The board facilitates rapid prototyping and testing, reducing time-to-market for LED lighting solutions. Its user-friendly GUI allows for seamless adjustments and real-time monitoring of the LED parameters.

Quality & Reliability

STMicroelectronics is known for its commitment to quality and reliability. The STEVAL-ILL074V1 is built with high-quality components and rigorous testing to ensure the highest standards are met, providing developers with confidence in their LED lighting projects.
