Products specifications

Category Development Boards, Kits, Programmers>Evaluation and Demonstration Boards and Kits
Mfr STMicroelectronics
Package Box
Product Status Not For New Designs
Type Opto/Lighting
Function Camera Flash
Embedded No
Utilized IC / Part STCF02
Supplied Contents Board(s)
Base Product Number STEVAL
Other Names -497-6235,497-6235,1805-STEVAL-TLL003V1,STEVALTLL003V1
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1284660-STEVAL-TLL003V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-TLL003V1 CAD Model

Description

STEVAL-TLL003V1 - LED Array Driver Evaluation Board by STMicroelectronics

The STEVAL-TLL003V1 evaluation board from STMicroelectronics is a sophisticated platform designed to showcase the capabilities of the LED1202 12-channel LED driver. This evaluation board is ideal for developers looking to create advanced lighting solutions with dimmable and programmable features for applications such as LCD backlighting, LED strips, and general-purpose LED lighting.

The LED1202 is a 12-channel low quiescent current LED driver which can be controlled via an I2C interface, providing precise brightness control through PWM dimming. This allows for fine-tuning of light intensity and can support advanced lighting effects. The driver operates over a wide input voltage range from 3V to 5.5V, making it versatile for use in various applications.

Key features of the STEVAL-TLL003V1 include:

  • 12 independently controlled outputs
  • 16 programmable steps for dimming control
  • Output error detection
  • Thermal shutdown and overcurrent protection
  • Flexible I2C communication interface

The evaluation board comes equipped with jumpers and connectors that enable easy configuration and integration with other development systems or prototypes. Its user-friendly interface ensures that developers can quickly set up and test their LED configurations, speeding up the development process.

With its built-in error detection and protection features, the STEVAL-TLL003V1 ensures reliable operation, protecting the system from common issues such as overheating or overcurrent conditions. This makes the board a safe choice for developing robust LED applications that require consistent performance and longevity.

For those looking to develop energy-efficient LED solutions with advanced control features, the STEVAL-TLL003V1 evaluation board by STMicroelectronics offers a comprehensive platform that combines flexibility, precision, and ease of use.
