The STGIPS20C60 is a cutting-edge IGBT (Insulated Gate Bipolar Transistor) from STMicroelectronics, designed to deliver high efficiency and power density in a wide range of applications. This device is a member of STMicroelectronics' SLLIMM™ (Small Low-Loss Intelligent Molded Module) family, which is renowned for its compact size and exceptional performance.

Key Features

• Integrated IGBTs: The module contains an inverter power stage with three IGBTs in a half-bridge configuration, allowing for efficient switching and control of electrical power.
• Advanced Technology: Utilizing STMicroelectronics' state-of-the-art IGBT technology, the STGIPS20C60 ensures reduced conduction and switching losses.
• High Current Rating: With a current rating of up to 20A and low saturation voltage, this device is capable of handling significant power levels while minimizing energy loss.
• High Voltage Capability: The device is rated for a maximum operating voltage of 600V, making it suitable for a variety of industrial applications.
• Built-in Bootstrap Diodes: Integrated high-speed bootstrap diodes are included to simplify the design of the driving circuitry for the high-side IGBTs.
• Over-Temperature Protection: Features include an over-temperature shutdown function to ensure the longevity and reliability of the module.
• Compact and Robust Package: Encased in a rugged and compact package, the STGIPS20C60 is designed for optimal thermal performance and space-saving on PCBs.

Applications

The STGIPS20C60 is ideal for a diverse array of applications, particularly where power efficiency and space constraints are critical. Common applications include:

• Motor Drives and Inverters
• UPS (Uninterruptible Power Supplies)
• Power Supply Units
• Welding Equipment
• Renewable Energy Systems

With its combination of high performance, integration, and reliability, the STGIPS20C60 is a superior choice for designers seeking to create sophisticated and energy-efficient power conversion systems. STMicroelectronics' commitment to innovation ensures that this IGBT module is a forward-thinking solution for modern electronic applications.
