Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type DC DC Regulator
Topology Step-Up (Boost)
Internal Switch(s) Yes
Number of Outputs 1
Operating Input Voltage(Min) 2.5V
Maximum Supply Voltage 18V
Output Voltage 27V
Channel Output Current 20mA
Frequency 2MHz
Dimming PWM
Applications Backlight
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 6-DFN-EP (2x2)
Win Source Part Number 038128-STLA02PUR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STLA02PUR CAD Model

Description

STLA02PUR Step-Down Converter by STMicroelectronics

The STLA02PUR is a highly efficient, monolithic synchronous step-down converter, designed and produced by STMicroelectronics. This advanced power solution is engineered to meet the rigorous demands of compact, low-voltage, and energy-sensitive applications. With its wide input voltage range and ability to provide a stable output, the STLA02PUR is an ideal choice for portable devices, IoT, and embedded systems.
