Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tube
Core Processor ARM Cortex-M0
Data Bus Width 32-Bit
Speed 48MHz
Connectivity CANbus, HDMI-CEC, I2C, IrDA, LINbus, SPI, UART/USART, USB
Peripherals DMA, I2S, POR, PWM, WDT
The number of I/O 16
Program Memory Size 32KB (32K x 8)
Program Memory Type FLASH
Date RAM Size 6K x 8
Supply Voltage 1.65V ~ 3.6V
Data Converters A/D 12x12b
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 20-TSSOP
Supplier Device Package 20-TSSOP
Manufacturer Pack Quantity 74
MSL Level 1 (Unlimited)
Win Source Part Number 708327-STM32F042F6P6
Series TPS series
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name STM32F042
ECCN 3A991.a.2
Country of Origin China, Philippines
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian STM32F042F6P6 CAD Model

Description

The STM32F042F6P6 is a high-performance ARM Cortex-M0 based microcontroller from STMicroelectronics designed to deliver the most efficient balance between power consumption and performance in its class. This microcontroller is particularly suitable for industrial control, consumer electronics, and smart home solutions due to its rich set of peripherals and I/O options.

Key Features:

  • Core: ARM Cortex-M0 CPU, operating at frequencies of up to 48 MHz.
  • Memory: It comes with 32 Kbytes of Flash memory and 6 Kbytes of SRAM, providing ample space for application code and data.
  • Communication Peripherals: It includes a comprehensive set of communication interfaces such as USB 2.0, CAN, I2C, USARTs, SPIs, and HDMI CEC.
  • Timers: Multiple timers including a 16-bit timer, a 32-bit timer, and a SysTick timer which can be used for RTOS task scheduling.
  • ADC: A 12-bit, 1.0 μs Analog-to-Digital Converter (ADC) with up to 16 channels for analog sensing capabilities.
  • Clock Control: Flexible clock control system with an internal 8 MHz factory-trimmed RC, and multiple PLL options.
  • Power Management: Low-power modes including Sleep, Stop and Standby to ensure optimal power efficiency.
  • I/O Ports: Up to 28 I/O ports with interrupt capability, which allows for easy connection to peripherals and direct sensor interfaces.
  • Package: Available in a TSSOP20 package, which is suitable for space-constrained applications.
  • Debugging: Integrated debugging and programming features with SWD (Serial Wire Debug) and bootloader support for firmware updates.

Applications:

The STM32F042F6P6 microcontroller is versatile and can be used in a wide range of applications. Its robust design and rich peripheral set make it ideal for:

  • Industrial automation and control systems
  • Consumer electronics
  • Smart home devices and IoT applications
  • Medical devices and equipment
  • Automotive applications

With its combination of performance, power efficiency, and design flexibility, the STM32F042F6P6 is a compelling choice for designers looking to create advanced and innovative applications.
