Products specifications

Country of Origin China, Malaysia, Philippines, Taiwan
Halogen Free Compliant
Estimated EOL Date 2029
ECCN 3A991.a.2
Introduction Date April 07, 2008
Family Name STM32F103RD
Supply and Demand Status Balance
Popularity High
Is this a common-used part? Yes
Win Source Part Number 031281-STM32F103RDT6
Case / Package 64-LQFP (10x10)
Temperature Range - Operating -40°C to 85°C (TA)
Data Converters A/D 16x12b; D/A 2x12b
Supply Voltage - Operating 2 V to 3.6 V
Data RAM Size 64K x 8
Program Memory Type FLASH
Program Memory Size 384KB (384K x 8)
Number of I/O 51
Speed(Frequency) 72MHz
Part Core Size 32-Bit
Core Processor ARM Cortex-M3
Status Active
Packaging Tray
Manufacturer STMicroelectronics
Categories Integrated Circuits
Ultra Librarian 3D Model Ultra Librarian STM32F103RDT6 CAD Model

Description

STM32F103RDT6 Microcontroller - STMicroelectronics

The STM32F103RDT6 is a high-performance ARM Cortex-M3 32-bit RISC core operating at a frequency of up to 72 MHz. This microcontroller from STMicroelectronics is part of their extensive STM32 family and is designed for embedded applications requiring a blend of power efficiency, performance, and reliability. With its robust set of peripherals and I/O capabilities, the STM32F103RDT6 is a versatile choice for projects ranging from industrial controls to consumer electronics.

Featuring 384 KB of flash memory and 64 KB of SRAM, this microcontroller provides ample storage for complex applications. It also supports a wide range of enhanced I/Os and peripherals connected to two APB buses. The device offers three general-purpose 16-bit timers plus one PWM timer, as well as standard and advanced communication interfaces: up to two I2Cs, three SPIs, two USARTs, an USB and a CAN.

The STM32F103RDT6 is equipped with a range of built-in features to ensure reliable operation under various conditions. These include a real-time clock, an independent watchdog, and a system window watchdog. It also provides an integrated single-wire debug module and an extensive set of power-saving modes, which make it suitable for battery-operated devices.

With its 64-pin LQFP package, the STM32F103RDT6 allows for a compact design footprint while still offering the flexibility of numerous GPIOs for interfacing with other components in a system. The device operates over a wide temperature range from -40°C to +85°C, making it a solid choice for demanding environments.

Developers can take advantage of the comprehensive development ecosystem for the STM32 family, which includes development tools, software libraries, and community support, to accelerate the design and development process. The STM32F103RDT6, with its mix of performance, power efficiency, and rich peripheral set, is an ideal microcontroller for applications that require high integration, flexibility, and a balanced cost-to-performance ratio.
