Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Reset Timer
Number of Voltages Monitored 1
Output Open Drain, Push-Pull
Reset Active High/Active Low
Reset Timeout Adjustable/Selectable
Voltage - Threshold 2.925V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 8-TDFN (2x2)
Win Source Part Number 037923-STM6513SEIEDG6F
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STM6513SEIEDG6F CAD Model

Description

The STM6513SEIEDG6F is a state-of-the-art dual push-button smart reset chip designed and manufactured by STMicroelectronics, a leader in the semiconductor industry. This compact and efficient component is specifically engineered to enhance the reliability and performance of electronic systems, particularly in the realm of consumer electronics, automotive applications, and industrial control systems.

Key Features

  • Smart Reset Input Delay: The device includes an adjustable smart reset input delay, which can be configured via external capacitor values. This allows designers to set the desired reset activation time, preventing unintentional resets due to brief button presses.
  • Dual Push-Button Interface: It supports a dual push-button interface, enabling system resets through the simultaneous activation of two push-buttons. This feature increases system security and prevents accidental system resets.
  • Low Supply Current: The STM6513SEIEDG6F operates with a very low supply current, making it an ideal choice for battery-powered applications where power conservation is crucial.
  • Wide Operating Voltage Range: With an operating voltage range from 1.65V to 5.5V, the device offers versatility and compatibility with a variety of digital systems.
  • High ESD Protection: The chip is designed with a high level of Electrostatic Discharge (ESD) protection, safeguarding the device from unforeseen electrical spikes and ensuring long-term reliability.

Applications

The STM6513SEIEDG6F is suitable for a wide range of applications, including:

  • Consumer Electronics (e.g., smartphones, tablets, and gaming consoles)
  • Automotive Systems (e.g., infotainment and navigation systems)
  • Industrial Control Systems
  • Computer Peripherals and Accessories

Package and Availability

This device is available in a compact, lead-free, 5-lead SOT23 package, ensuring minimal footprint and ease of integration into existing and new designs. The STM6513SEIEDG6F is available for order through STMicroelectronics' distribution channels, ensuring global availability and support.

In conclusion, the STM6513SEIEDG6F from STMicroelectronics is a robust and versatile smart reset chip that offers designers a reliable solution for system reset functionality with enhanced security features. Its low power consumption and wide voltage range make it a suitable choice for a broad spectrum of electronic applications.
