The STM8S003K3T6C is a robust and versatile 8-bit microcontroller from STMicroelectronics, designed to deliver high performance and efficiency for a wide range of embedded applications. This microcontroller is part of the STM8S Value Line series that offers an excellent balance between cost and features, making it an ideal choice for budget-conscious yet demanding projects.

Key Features

• Core: STM8 core operating at up to 16 MHz.
• Program Memory: 8 KB Flash memory with read-while-write support.
• Data Storage: 1 KB RAM and 128 bytes of EEPROM.
• I/O Ports: Up to 28 I/O pins, providing a mix of GPIOs, which include 5V tolerant and high sink capabilities.
• Timers: Advanced control timer, two general-purpose timers, and an 8-bit basic timer.
• Communication Interfaces: Integrated UART, SPI, and I2C interfaces for serial communication.
• Analog Features: 10-bit ADC with up to five channels and a single analog comparator.
• Supply Voltage: 2.95V to 5.5V operating range.
• Temperature Range: Industrial temperature range from -40°C to 85°C.

Applications

The STM8S003K3T6C is suitable for a broad array of applications due to its rich set of peripherals and interfaces. Typical applications include:

• Consumer electronics
• Home appliances
• Industrial control systems
• Automotive systems
• Lighting control
• Power management systems

Development Support

STMicroelectronics provides extensive support for the STM8S003K3T6C with development tools and software libraries. The STM8S series is supported by the ST Visual Develop (STVD) IDE and the ST Visual Programmer (STVP). Additionally, there are various starter kits and development boards available to expedite the prototyping process and reduce time-to-market.

With its robust set of features and support for multiple communication protocols, the STM8S003K3T6C stands as a cost-effective solution for designers looking to implement a microcontroller with a small footprint, low power consumption, and a high degree of functionality.
