Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Logic Type Shift Register
Output Type Push-Pull
Number of Elements 1
Number of Bits per Element 8
Purpose Serial to Parallel
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 16-HTSSOP
Win Source Part Number 053910-STP08CP05XTTR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STP08CP05XTTR CAD Model

Description

The STP08CP05XTTR is a cutting-edge LED driver integrated circuit (IC) developed by STMicroelectronics, a global leader in semiconductor solutions. This device is specifically designed to enhance the performance and reliability of LED lighting applications. It is part of the STP08CP05 series, which is known for its low-voltage power supply capability and high efficiency.

Key Features

  • Shift Register: The STP08CP05XTTR boasts an 8-bit serial-in, parallel-out shift register that allows for the conversion of serial input data into parallel output format, enabling the control of multiple LEDs with minimal microcontroller pins.
  • Output Current Control: Each of the 8 output channels can sink up to 100 mA of current, allowing for the direct drive of LEDs with consistent brightness and color.
  • Constant Output Current: The device ensures a constant output current that is programmable through an external resistor, which is vital for uniform illumination and to extend the lifespan of the LEDs.
  • Low Voltage Operation: It operates at a low voltage range, making it suitable for battery-powered applications and contributing to energy savings.
  • Thermal Shutdown: The integrated thermal shutdown feature protects the IC from overheating, ensuring safe operation and longevity of the product.
  • Error Detection: The STP08CP05XTTR includes an error detection circuitry that monitors the output error conditions, enhancing the reliability of the LED system.

Applications

The STP08CP05XTTR is versatile and can be used in a wide range of applications including:

  • LED Display Panels
  • LED Backlighting
  • Automotive Lighting
  • Portable and Battery-Powered Devices
  • Signal and Symbol Indicators

Package and Quality

This device is offered in a TSSOP16 package, which is known for its compact footprint and suitability for space-constrained applications. The STP08CP05XTTR is designed and manufactured to meet the highest quality and reliability standards that are synonymous with STMicroelectronics' products.

In summary, the STP08CP05XTTR from STMicroelectronics is an excellent choice for designers looking to create efficient, reliable, and high-performance LED lighting solutions.
