Products specifications

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 395mV @ 1A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 200μA @ 30V
Mounting SMD (SMT)
Case / Package SMB
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 031501-STPS1L30U
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STPS1L30U CAD Model

Description

The STPS1L30U is a robust and efficient Schottky diode, designed and manufactured by STMicroelectronics, a leader in semiconductor solutions. This diode is specifically engineered to offer low forward voltage drop while providing superior switching performance, making it an ideal choice for a variety of applications. Its ultra-compact package allows for easy integration into space-constrained designs.

Key Features

  • Low Forward Voltage Drop: The STPS1L30U boasts a low forward voltage drop, which enhances overall system efficiency by minimizing power loss during conduction.
  • High Junction Temperature: With a maximum junction temperature of 150°C, this Schottky diode is suitable for operation in high-temperature environments.
  • Low Leakage Current: The device exhibits a very low reverse leakage current, contributing to reduced power consumption when in the off-state.
  • Fast Switching Capability: Its fast switching response is ideal for high-frequency applications, reducing switching losses and improving performance.
  • Surface-Mount Device: The STPS1L30U comes in an SMA (DO-214AC) surface-mount package, which is compatible with automatic pick-and-place equipment, facilitating efficient manufacturing processes.
  • Power Rectification: It is well-suited for use in power rectification applications, thanks to its ability to handle continuous forward currents up to 1 A.

Applications

The STPS1L30U is versatile and can be used in a wide range of applications, including:

  • Switching power supplies
  • Power management systems
  • DC-DC converters
  • Free-wheeling diodes in motor control circuits
  • Reverse battery protection
  • Or-ing diode in redundant power systems

Reliability and Quality

STMicroelectronics is committed to delivering high-quality products. The STPS1L30U Schottky diode is no exception, as it is built to meet the stringent requirements of industrial and consumer electronic applications. Its reliability is assured through rigorous testing and adherence to international quality standards.
