Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Tube/Rail
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 1200V (1.2kV)
Current - Average Rectified (Io) 30A
Voltage - Forward (Vf) (Max) @ If 2.25V @ 30A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 115ns
Current - Reverse Leakage @ Vr 20μA @ 1200V
Mounting Through Hole
Case / Package DO-247
Operating Temperature - Junction 175°C (Max)
Win Source Part Number 212410-STTH3012W
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Power Management
Ultra Librarian 3D Model Ultra Librarian STTH3012W CAD Model

Description

The STTH3012W, manufactured by STMicroelectronics, is a state-of-the-art ultrafast high voltage rectifier designed specifically for switching power supplies and other power conversion systems. This component is especially suitable for high-efficiency applications thanks to its exceptionally low forward voltage drop and superior reverse recovery performance.

Key Features

  • Voltage Ratings: The rectifier has a repetitive peak reverse voltage (V<sub>RRM) of 1200 V, making it ideal for high voltage applications.
  • Current Capacity: It can handle an average forward current (I<sub>F(AV)) of up to 30 A, ensuring reliable operation in demanding conditions.
  • Ultrafast Recovery Time: With an ultrafast recovery time, this device minimizes energy loss and improves the efficiency of the application it's used in.
  • Low Forward Voltage Drop: The STTH3012W features a low forward voltage drop, reducing power dissipation and heat generation.
  • High Surge Current Capability: It can withstand high surge currents, which is essential for protecting circuits against unexpected voltage spikes.

Applications

The STTH3012W is versatile and can be used in a variety of applications, including:

  • Switched-mode power supplies (SMPS)
  • Uninterruptible power supplies (UPS)
  • High-frequency converters and inverters
  • Freewheeling diodes in motor control circuits
  • Power factor correction circuits (PFC)

Package and Installation

This powerful rectifier comes in a fully insulated ISOWATT220AB package, which not only simplifies installation but also ensures a high level of safety by maintaining electrical isolation from the mounting surface. The package is optimized for use in compact designs where space is at a premium.

Quality and Reliability

STMicroelectronics is known for its commitment to quality and reliability. The STTH3012W is built to meet the stringent requirements of the most demanding electronic systems, ensuring long-term performance and durability.
