The STU60N3LH5 is a state-of-the-art N-channel Power MOSFET produced by STMicroelectronics, a leader in semiconductor solutions. This device is part of the STripFET™ V series, which is renowned for its low on-state resistance (R<sub>DS(on)) and excellent switching performance. The STU60N3LH5 is designed for a wide range of applications, including high-efficiency power management, automotive systems, and other power-intensive applications.

Key Features

• Low Threshold Drive: The device can be driven at lower gate voltages, allowing for compatibility with a wider range of drive circuits and controllers.
• High Current Capability: With a continuous drain current (I<sub>D) of 60A, the STU60N3LH5 can handle high current loads efficiently, making it suitable for demanding power applications.
• Low On-Resistance: An R<sub>DS(on) value as low as 8.7 mΩ (max) at 10V contributes to reduced power losses and improved overall efficiency.
• 100% Avalanche Tested: Ensures robustness and reliability of the device under extreme conditions.
• Low Gate Charge: This feature leads to reduced switching losses and faster switching speeds, enhancing the performance of power conversion systems.

Applications

The STU60N3LH5 is suitable for a multitude of applications including, but not limited to:

• High-efficiency DC/DC converters
• Synchronous rectification for power supplies
• Motor control systems
• Automotive applications and power management systems

Package and Quality

The STU60N3LH5 is housed in a DPAK (TO-252) package, which is designed for surface mounting on printed circuit boards. The package is compact and offers a good balance between thermal performance and footprint. STMicroelectronics ensures that the STU60N3LH5, like all of their products, meets high-quality standards and is compliant with environmental regulations, including RoHS.
