STMicroelectronics TDA7233D013TR Audio Amplifier

The TDA7233D013TR from STMicroelectronics is a monolithic integrated circuit designed to provide high-quality audio amplification with minimal external components and a compact footprint. This audio amplifier IC is specifically tailored for mobile devices and portable applications, where power efficiency and size are critical considerations.

Key Features

• Output Power: The TDA7233D013TR delivers 1W of continuous RMS output power when connected to an 8Ω load with a 6V power supply, making it suitable for a variety of audio playback devices.
• Low Voltage Operation: It operates effectively at a supply voltage range from 1.8V to 6V, ensuring compatibility with a wide range of battery-operated devices.
• High Efficiency: The amplifier's class AB operation offers a good compromise between efficiency and audio performance, reducing power loss and extending battery life in portable applications.
• Minimal External Components: Its design requires very few external components, which simplifies circuit design and reduces overall system cost.
• Thermal Shutdown Protection: The built-in thermal shutdown feature protects the IC from overheating, enhancing the reliability and longevity of the product.

Applications

The TDA7233D013TR is ideal for a variety of audio applications, such as:

• Portable audio devices (e.g., MP3 players, portable speakers)
• Mobile phones and tablets
• Personal digital assistants (PDAs)
• Portable gaming systems
• Small home audio systems

Packaging and Quality

This audio amplifier is available in an 8-pin SO package, ensuring a small form factor suitable for space-constrained applications. The TDA7233D013TR is part of STMicroelectronics' commitment to high-quality and reliable semiconductor products, meeting stringent industry standards for performance and durability.
