The TSV634IPT is a cutting-edge operational amplifier designed by STMicroelectronics, a leader in semiconductor solutions. This operational amplifier is part of the TSV family, which is known for its low power consumption and high accuracy. The TSV634IPT is a quad operational amplifier, which means it contains four op-amp units in a single package, making it an ideal choice for space-constrained applications.

Key Features

• Low Power Consumption: The TSV634IPT is designed for applications that require high efficiency, with a typical low supply current of 60 µA per channel, which is ideal for battery-powered devices.
• Wide Supply Voltage Range: This op-amp operates over a wide supply voltage range from 1.5 V to 5.5 V, providing design flexibility for various applications.
• High Gain Bandwidth Product: With a gain bandwidth product of 1 MHz, the TSV634IPT is capable of handling a wide range of frequencies, making it suitable for audio processing, filtering, and signal conditioning.
• Rail-to-Rail Input and Output: The device features rail-to-rail input and output, which allows for a wider dynamic range and better signal representation, especially in low-voltage applications.
• Low Input Offset Voltage: A low input offset voltage minimizes errors in signal amplification, ensuring high accuracy in measurement and control systems.

Applications

The versatility of the TSV634IPT makes it appropriate for a broad array of applications. It is particularly useful in sensor signal conditioning, battery-powered devices, portable medical equipment, and any application where energy efficiency is crucial. Additionally, its compact package and integrated quad-channel configuration make it a space-saving solution for complex circuit designs.

Package Information

The TSV634IPT comes in a TSSOP14 package, which is a thin-shrink small outline package with 14 leads. This package is known for its small footprint and low profile, making it suitable for compact PCB layouts.
