Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 1
Output Type Rail-to-Rail
Slew Rate 4.5 V/μs
Gain Bandwidth Product (GBP) 8MHz
Current - Input Bias 1pA
Voltage - Input Offset 100μV
Operating Supply Current 820μA
Channel Output Current 35mA
Supply Voltage - Operating 2.5 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 035411-TSV911ILT
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TSV911ILT CAD Model

Description

Introducing the TSV911ILT Operational Amplifier from STMicroelectronics

The TSV911ILT is a cutting-edge operational amplifier (op-amp) designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This op-amp is part of the TSV911 family, known for its high precision and low-power consumption, making it an ideal choice for a wide range of electronic applications.

The TSV911ILT is characterized by its single-supply operation, with a voltage range from 2.5V to 5.5V, which allows for flexibility in various circuit designs. It boasts a low input offset voltage and a rail-to-rail input/output, which ensures a wide dynamic range and improved performance. The device is particularly suited for battery-powered applications due to its low power consumption, with a typical quiescent current of only 29 µA.

With a gain bandwidth product of 8 MHz and a slew rate of 4 V/µs, the TSV911ILT provides a fast and accurate response, making it suitable for applications requiring good transient response. Its excellent frequency response and stability are complemented by a phase margin of 60 degrees and a gain margin of 12 dB, ensuring reliable operation even in challenging conditions.

The TSV911ILT comes in a compact 5-pin SOT23-5 package, which is perfect for space-constrained applications. Its small footprint does not compromise its performance and reliability, which are hallmarks of STMicroelectronics' products. The device is also fully specified over the extended temperature range of -40°C to +125°C, making it robust for industrial applications.

Applications that can benefit from the TSV911ILT include sensor signal conditioning, portable and battery-powered devices, active filtering, and medical instrumentation. Its low input bias current and low noise make it particularly well-suited for high-impedance sensor interfaces and precision analog processing.

In summary, the TSV911ILT from STMicroelectronics is a high-performance, low-power operational amplifier that offers excellent accuracy, stability, and flexibility for designers seeking to optimize their electronic circuits. Its robust features and compact design make it a top choice for a multitude of applications where efficiency and reliability are paramount.
