The CBC2518T220K is a 22µH ±10% SMD (Surface Mount Device) wire-wound inductor from Taiyo Yuden. This inductor is designed for use in power supplies, RF circuits, and other applications where inductance is required for filtering, energy storage, or impedance matching. It offers compact size and reliable performance within a specified operating temperature range.

Applications

• DC-DC converters
• Power supplies
• RF circuits
• EMI filtering
• Impedance matching

Features

• Inductance: 22 µH (Microhenries)
• Tolerance: ±10%
• Mounting Type: Surface Mount Device (SMD)
• Case Size: 2518 (2.5mm x 1.8mm)
• DC Resistance (DCR): Typically around 0.2 Ohms (Consult datasheet for exact value)
• Self-Resonant Frequency (SRF): Typically in the MHz range (Consult datasheet for exact value)
• Rated Current: (Consult datasheet for exact value, typically in the hundreds of mA)

Benefits

• Compact Size: Small footprint makes it suitable for space-constrained applications.
• Precise Inductance: Provides a specific inductance value with a tolerance of ±10%.
• Reliable Performance: Taiyo Yuden is a reputable manufacturer known for high-quality components.
• Suitable for SMD Assembly: Designed for automated surface mount assembly processes.
• Versatile Application: Can be used in various electronic circuits requiring inductance.

Additional Details

The CBC2518T220K inductor is constructed with a wire-wound coil on a ferrite core. Its operating temperature range typically spans from -40°C to +125°C, making it suitable for a wide range of environments. The specific rated current and self-resonant frequency will depend on the exact specifications as detailed in the Taiyo Yuden datasheet for this part number. Consult the datasheet for detailed performance characteristics and application recommendations. This inductor is commonly used in power management circuits within mobile devices and other compact electronic equipment.
