Same model may have multiple batches, images only for reference.
LGJ12565TS-152MR37-H TDK Corporation – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

LGJ12565TS-152MR37-H

Part No LGJ12565TS-152MR37-H
Manufacturer TDK Corporation
Catalog Fixed Inductors
Description FIXED IND 1.5MH 400MA 2.8OHM SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 1.5 mH
Tolerance ±20%
Current Rating (Amps) 400 mA
Current - Saturation (Isat) 370mA
Shielding Shielded
DC Resistance (DCR) 2.8Ohm
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 1 kHz
Mounting Type Surface Mount
Case / Package Nonstandard
Size / Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height - Seated (Max) 0.256\
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1532509-LGJ12565TS-152MR37-H
Ultra Librarian 3D Model Ultra Librarian LGJ12565TS-152MR37-H CAD Model
