Same model may have multiple batches, images only for reference.
RLF7030T-3R3M4R1 Real Image
Same model may have multiple batches, images only for reference.

RLF7030T-3R3M4R1

Part No RLF7030T-3R3M4R1
Manufacturer TDK Corporation
Catalog Fixed Inductors
Description FIXED IND 3.3UH 4.1A 17.4 MOHM
Datasheet
RLF7030T-3R3M4R1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer TDK Corporation
Packaging Reel - TR
Status Active
Type Wirewound
Material - Core Ferrite
Inductance 3.3μH
Tolerance ±20%
Current Rating 4.1A
Current - Saturation 4.4A
DC Resistance (DCR) 20.88 mOhm Max
Temperature Range - Operating -40°C to 125°C
Frequency - Test 100kHz
Mounting SMD (SMT)
Height - Seated (Max) 0.126" (3.20mm)
Win Source Part Number 027440-RLF7030T-3R3M4R1
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian RLF7030T-3R3M4R1 CAD Model

Description

The TDK Corporation wirewound part with a Win Source Part Number of 027440-RLF7030T-3R3M4R1 is a common-used part with high popularity.

  • Part Type: inductor, coil, choke
  • Current Rating: 4.1A
  • Inductance: 3.3μH
  • Tolerance: ±20%
  • Core Material: ferrite
  • DC Resistance: 20.88 mOhm Max
