The VLF3012AT-4R7MR7 is a TDK Corporation power inductor, specifically designed for use in compact electronic devices. Part of the VLF series, this shielded inductor is known for its small size, low profile, and excellent performance in DC-DC converters and power management circuits. The shielding helps to minimize electromagnetic interference (EMI), making it suitable for use in sensitive applications.

Applications:

• DC-DC Converters: Used in step-up (boost), step-down (buck), and buck-boost converters to store energy and filter noise.
• Power Management Circuits: Integrated into power management units (PMUs) to regulate voltage and current.
• Mobile Devices: Suitable for use in smartphones, tablets, and other portable devices due to its small size and efficiency.
• Wearable Electronics: Ideal for smartwatches, fitness trackers, and other wearable devices where space is limited.
• Audio Equipment: Used in audio amplifiers and other audio circuits for filtering and noise reduction.

Features:

• Shielded Construction: Minimizes electromagnetic interference (EMI).
• Small Size and Low Profile: Allows for high-density mounting on PCBs.
• Low DC Resistance (DCR): Reduces power loss and improves efficiency.
• High Saturation Current: Can handle high current levels without significant performance degradation.
• Excellent Temperature Stability: Maintains consistent performance over a wide temperature range.

Benefits:

• Reduced EMI: Shielding helps prevent interference with other components in the system.
• Space-Saving Design: Small size and low profile allow for use in compact electronic devices.
• Improved Efficiency: Low DCR minimizes power dissipation, increasing overall efficiency.
• High Performance: High saturation current enables efficient energy storage and filtering.
• Reliable Operation: Excellent temperature stability ensures consistent performance under varying conditions.

Additional Details:

The VLF3012AT-4R7MR7 has an inductance value of 4.7μH (4R7). The dimensions of the component are approximately 3.0 x 1.2 mm. Key specifications include the saturation current (Isat) and the rated current (Irms). The saturation current indicates the current level at which the inductance starts to drop significantly, while the rated current represents the maximum continuous current the inductor can handle without overheating. Consult the TDK datasheet for detailed electrical characteristics, application notes, and soldering recommendations. Proper PCB layout and soldering techniques are crucial for achieving optimal performance and reliability.
