VLS3012CX-2R2M-1 TDK Corporation – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

VLS3012CX-2R2M-1

Part No VLS3012CX-2R2M-1
Manufacturer TDK Corporation
Catalog Fixed Inductors
Description FIXED IND 2.2UH 2.83A 74MOHM SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 2.2 µH
Tolerance ±20%
Current Rating (Amps) 2.83 A
Current - Saturation (Isat) 1.89A
Shielding Shielded
DC Resistance (DCR) 74mOhm Max
Temperature Range - Operating -40°C ~ 105°C
Inductance Frequency - Test 1 MHz
Mounting Type Surface Mount
Case / Package Nonstandard
Size / Dimension 0.118" L x 0.118" W (3.00mm x 3.00mm)
Height - Seated (Max) 0.047\
Package Tape & Reel
Supply and Demand Status Normal
Win Source Part Number 1509722-VLS3012CX-2R2M-1
Ultra Librarian 3D Model Ultra Librarian VLS3012CX-2R2M-1 CAD Model
