The VLS3015T-2R2M is a shielded power inductor manufactured by TDK Corporation. This inductor is designed for use in power supply circuits and DC-DC converters, offering excellent performance in a small package. It features a magnetically shielded construction to minimize electromagnetic interference (EMI) and is well-suited for applications requiring high efficiency and compact size.

Applications

• DC-DC converters
• Power supplies for portable devices
• Power management circuits in smartphones and tablets
• Noise filtering in signal lines
• Voltage regulators

Features

• Magnetically shielded construction
• Small size (3.0 x 1.5 x 1.0 mm)
• Low DC resistance
• High current handling capability
• Excellent EMI performance
• Operating temperature range

Benefits

• Reduces electromagnetic interference, simplifying compliance with EMI regulations.
• Saves board space due to its compact size, enabling smaller and more portable devices.
• Improves efficiency and reduces power losses due to low DC resistance.
• Handles high currents without saturation, ensuring stable operation in demanding applications.
• Provides reliable performance over a wide temperature range.
• Enables the design of high-performance power supply circuits.

Additional Details

The 2R2M designation indicates an inductance value of 2.2 μH. The saturation current and rated current are important parameters to consider when selecting this inductor for a specific application. The saturation current is the current at which the inductance value drops significantly, while the rated current is the maximum continuous current that the inductor can handle without exceeding its temperature rating. The TDK datasheet provides detailed specifications, including inductance tolerance, DC resistance, saturation current, rated current, and self-resonant frequency. Proper PCB layout is crucial for minimizing EMI and maximizing performance. Consult the manufacturer's datasheet for recommended layout guidelines and application notes.
