ZJYS51R5-2PT-01

Part No ZJYS51R5-2PT-01
Manufacturer TDK Corporation
Catalog Common Mode Chokes
Description CMC 2A 2LN 200 OHM SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Filters
Manufacturer TDK Corporation
Packaging Reel - TR
Filter Type Signal Line
Number of Lines 2
Impedance @ Frequency 200 Ohm @ 100MHz
Current Rating (Max) 2A
DC Resistance (DCR) (Max) 120 mOhm
Voltage Rating - DC 50V
Temperature Range - Operating -25°C to 85°C
Mounting SMD (SMT)
Height (Max) 0.200" (5.08mm)
Dimension Horizontal, 4 Gull Wing
Win Source Part Number 036728-ZJYS51R5-2PT-01
Family Name ZJYS
Introduction Date July 26, 2001
ECCN EAR99
Country of Origin Japan
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian ZJYS51R5-2PT-01 CAD Model

Description

The TDK Corporation ZJYS series signal line filter is a common-used part with high popularity and sufficient supply and demand status.

  • Voltage Rating: 50V
  • Maximum Current Rating: 2A
  • Filter Type: Signal line
  • Lines: Two lines
  • Impedance: 200 Ohm @ 100MHz
  • Inductance @ Frequency: Not specified
  • DC Resistance (DCR): 120 mOhm max
  • Mounting: SMD (SMT)
  • Height: 0.200" (5.08mm)
  • Package: Reel - TR
  • Temperature Range: -25°C to 85°C
  • Orientation: Horizontally oriented with four gull wings
  • ECCN: EAR99
  • Alternative Parts: ZJYS51R5-2PB-01, ACP3225-102-2P-T000, and ACT45B-510-2P-TL003
