Same model may have multiple batches, images only for reference.
ST3P3LB2 Real Image
Same model may have multiple batches, images only for reference.

ST3P3LB2

Part No ST3P3LB2
Manufacturer TE Connectivity
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE SPDT 6A 12V / General Purpose Relay SPDT (1 Form C) 12VDC Coil DIN Rail
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays>Power Relays, Over 2 Amps
Mfr TE Connectivity Potter & Brumfield Relays
Series SNR, SCHRACK
Package Bulk
Mounting Type DIN Rail
Coil Voltage 12VDC
Contact Form SPDT (1 Form C)
Contact Rating (Current) 6 A
Switching Voltage 400VAC - Max
Coil Current 14.2 mA
Coil Type Non Latching
Features Socket Included
Termination Style Screw Terminal
Seal Rating Sealed - Fully
Must Operate Voltage 8.4 VDC
Must Release Voltage 0.6 VDC
Operate Time 12 ms
Release Time 5 ms
Temperature Range - Operating -40°C ~ 55°C
Contact Material Silver Tin Oxide (AgSnO)
Relay Type General Purpose
Coil Resistance 848 Ohms
Base Product Number ST3P
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.41.0020
Other Names PB2040,-3-1416100-1-SI,3-1416100-1-ND,ST3P3LB2-ND,3-1416100-1,-ST3P3LB2-SI-ND,-ST3P3LB2-SI
Standard Package 10
Win Source Part Number 1031425-ST3P3LB2
Ultra Librarian 3D Model Ultra Librarian ST3P3LB2 CAD Model

Description

The SNR, SCHRACK ST3P3LB2 is a general-purpose power relay that has a contact rating of 6A and a switching voltage of 400VAC.

  • Contact Rating: 6A
  • Switching Voltage: 400VAC
  • Contact Form: SPDT (1 Form C)
  • Mounting: DIN rail
  • Coil Voltage: 12VDC
  • Coil Resistance: 848 ohms
  • Operate Time (max): 12ms
  • Release Time: 5ms
  • Packaging: Bulk
  • Socket: Included
  • Supply and Demand: Balanced
