Product Overview: 74LVC16373ADGVRE4 by Texas Instruments

The 74LVC16373ADGVRE4 is a high-performance, low-voltage 16-bit transparent D-type latch with 3-state outputs from Texas Instruments. Designed for use in applications requiring high-speed data storage and transfer, this integrated circuit is part of the 74LVC family, which is renowned for its low-voltage operation and compatibility with 5V systems.

This product operates from a 1.65V to 3.6V V<sub>CC supply voltage, making it ideal for interfacing with modern microprocessors and digital signal processors that require a lower operating voltage. The device features 16 D-type transparent latches with 3-state outputs, which means that each latch can hold its input state until the enable signal is activated, at which point the input is transferred to the output. When the output enable (OE) is high, the output is in a high-impedance state, allowing for bus connectivity without the risk of data contention.

The 74LVC16373ADGVRE4 is characterized for operation from -40°C to +85°C, ensuring reliable performance across a wide range of environmental conditions. Additionally, the device supports 5V tolerant inputs, which allows for direct interfacing with 5V TTL logic without the need for additional level shifting hardware.

Key features of the 74LVC16373ADGVRE4 include:

• Low-voltage operation: 1.65V to 3.6V
• High-speed performance: Ensures swift data transfer and processing
• 16 transparent D-type latches: For efficient data storage
• 3-state outputs: Facilitates bus-connected applications
• 5V tolerant inputs: Provides compatibility with 5V systems
• Wide operating temperature range: -40°C to +85°C for use in various environments

The device is packaged in a TVSOP (Thin Very Small Outline Package) form, which is not only space-saving but also conducive for PCB design and layout. The 74LVC16373ADGVRE4 is an excellent choice for system designers looking for a latch that combines low-power consumption with high-speed data transfer capabilities, making it suitable for a broad array of applications, including computing, telecommunications, and consumer electronics.

With Texas Instruments' reputation for quality and reliability, the 74LVC16373ADGVRE4 is a dependable component for your digital storage and interfacing needs.
