CC2531F256RHAR Real Image CC2531F256RHAR real image2959 CC2531F256RHAR real image2960 CC2531F256RHAR real image2961
Same model may have multiple batches, images only for reference.
CC2531F256RHAR Real Image CC2531F256RHAR real image2959 CC2531F256RHAR real image2960 CC2531F256RHAR real image2961
CC2531F256RHAR Real Image CC2531F256RHAR real image2959 CC2531F256RHAR real image2960 CC2531F256RHAR real image2961
Same model may have multiple batches, images only for reference.

CC2531F256RHAR

Part No CC2531F256RHAR
Manufacturer Texas Instruments
Catalog RF Transceiver ICs
Description IC RF TXRX+MCU 802.15.4 40-VFQFN
Datasheet
CC2531F256RHAR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type TxRx + MCU
RF Family/Standard 802.15.4
Protocol Zigbee
Frequency 2.4GHz
Data Rate (Max) 250kbps
Power - Output 4.5dBm
Sensitivity -97dBm
Memory Size 256kB Flash, 8kB RAM
Serial Interfaces SPI, USART, USB
GPIO 21
Supply Voltage - Operating 2 V to 3.6 V
Current - Receiving 20.5mA to 24.3mA
Current - Transmitting 28.7mA to 33.5mA
Temperature Range - Operating -40°C to 125°C
Dimension 40-VFQFN Exposed Pad
Win Source Part Number 012774-CC2531F256RHAR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian CC2531F256RHAR CAD Model

Description

CC2531F256RHAR

The CC2531F256RHAR offers an enhanced take on wireless communication by combining a superior 2.4GHz RF transceiver with an industry-standard microcontroller in one package. Designed for ZigBee PRO operations, it caters to a broad range of short-range wireless applications.

  • Applications:
    • Wireless Data Acquisition Systems
    • Home Automation Networks
    • Smart Energy Devices
    • Healthcare Monitoring Systems
  • Features and Benefits:
    • 256KB Flash Memory
    • Advanced Security options with AES
    • High Sensitivity and Selectivity
    • Seamless Integration with ZigBee Networks
  • Additional Details:
    • Temperature Range: -40°C to 125°C
    • QFN32 Package
    • Wide Voltage Supply Range (2.0V - 3.6V)
